JSC «Kerammash»
Joint Stock Company «Institute for Ceramic Mashinebuilding «Kerammash», Ukraine, Slavyansk, fax: +38 (0626) 667338

Industrial Ovens and Dryers

for bulk, plastic and other materials drying and heating

Ovens and drying furnaces are designed for materials drying, preheating, calcination and testing in laboratory and industrial environment. Extended temperature range up to 500°С allows substances drying and calcination with the release of chemically bound water.

Industrial drying furnace electrically heated Drying furnace electrically heated
[ ThermoMaster ] ТермоМастер ®-ДО-13.23.13/200
is provided for items drying after painting in the oxidizing atmosphere
Working chamber
usable volume,
m3		 Maximum
heating temperature,
°С		 Installed
capacity,
kW
4,2 200 37,8 ±5%
Drying furnace - [ ThermoMaster ] ТермоМастер ®-1,1/120
is provided for ceramics raw material, specimen and ceramic items drying.
Working chamber
usable volume,
m3		 Maximum
heating temperature,
°С		 Installed
capacity,
kW
1,1 120 I-7,5
II-3,7
III-1,7
Industrial drying furnace electrically heated Drying furnace - [ ThermoMaster ] ТермоМастер ®-1,75/75
is provided for work clothes and other materials drying.
Working chamber
usable volume,
m3		 Maximum
heating temperature,
°С		 Installed
capacity,
kW
1,75 75 I-6
II-3
Batch drying cabinet
is provided for welding rods drying.
Working chamber
usable volume,
m3		 Maximum
heating temperature,
°С		 Installed
capacity,
kW
0,3 100 6
Batch drying furnace - [ ThermoMaster ] ТермоМастер ®-0,14/400
is provided for welding rods heating.
Working chamber usable volume,
m3		 Maximum heating temperature,
°С		 Installed capacity,
kW
0,14 400 1,5 ±10%
Batch drying furnace
is provided for materials (bricks, roof tile, ceramics) drying.
Efficiency
as to wet items,
kg/h		 Loaded car dimensions,
mm		 Number of cars Installed capacity,
kW
width length height
37,5 1100 1400 1850 6 23,3
Drying furnace - [ ThermoMaster ] ТермоМастер ®-1/400
is provided for welding rods heating.
Working chamber usable volume,
m3		 Maximum heating temperature,
°С		 Installed capacity,
kW
1 350-400 30
Drying furnace - [ ThermoMaster ] ТермоМастер ®-0,3/350
is provided for welding rods heating.
Working chamber usable volume,
m3		 Maximum heating temperature,
°С		 Installed capacity,
kW
0,3 350-400 12 ± 5%
Drying furnace - [ ThermoMaster ] ТермоМастер ®-0,3/350
is provided for bulk and plastic materials heating .
Working chamber usable volume,
m3		 Maximum heating temperature,
°С		 Installed capacity,
kW
0,3 350 9,6
Drying furnaces series - [ ThermoMaster ] ТермоМастер ® have:
